Rotary/Digital Code Switch

product
BTNR100H SERIES BTNR100H SERIES
Miniaturized rotary switch with 12 positioned max.

- Designed for P.C.Board mounting version
- Miniaturized size (10 mm : height X 30 mm : width)
- 5 mm mounting height from shaft-center to P.C.Board
- All switch contacts are plated by gold
BTNR100H Series.pdf
BTNR100H Series.pdf
BTSR10H SERIES BTSR10H SERIES
Miniaturized rotary switch with multi-functions

- Designed for P.C.Board mounting version
- Miniaturized size (12 mm : height X 10 mm : width)
- 6.5 mm mounting height from shaft-center to P.C.Board
BTSR10H SERIES.pdf
BTSR10H SERIES.pdf
BTSR16H SERIES BTSR16H SERIES
General purpose rotary switch with compact ganged design

- Designed for general purpose electric and electronic equipments
- P.C.Board mounting type and compact size (21 mm : height X 16.2 mm : width)
- 12.5 mm height from shaft center to P.C.Board
BTSR16H SERIES.pdf
BTSR16H SERIES.pdf
BTSR12V SERIES BTSR12V SERIES
Simplest switch function with low-profile vertical mounting
& available reflow solderable type

- 4 mm height low-profile vertical switch
- Miniaturized size (13 mm X 12.4 mm : width X 4 mm : height)
- Reflow solderable type available
BTSR12V SERIES.pdf
BTSR12V SERIES.pdf
BTSR18V SERIES BTSR18V SERIES
Low-profile vertical rotary switch with compact design

- Low-profile one section vertical mounting structure
- Compact size (17 mm X 18.7 mm : width X 7.5 mm : height)
- Changeable plastic shaft length
BTSR18V SERIES.pdf
BTSR18V SERIES.pdf
BTDS10 SERIES (DIGITAL SWITCHES) BTDS10 SERIES (DIGITAL SWITCHES)
Rotary type digital switch with compact size and gold plated contacts
specially for the communication equipments

- Small and compact size (10 X 11.5 mm)
- Detent number from 4 to 16 are available
- Capable for horizontal and vertical mounting
- All contact points and terminals are plated by gold plating
BTDS10 SERIES (DIGITAL SWITCHES).pdf
BTDS10 SERIES (DIGITAL SWITCHES).pdf
BTDS20H SERIES (DIGITAL SWITCHES) BTDS20H SERIES (DIGITAL SWITCHES)
Rotary type digital switch with small and compact size

- Small and compact size (20 X 20.5 mm)
- Detent number from 8 to 40 are available
- Capable for horizontal and vertical mounting
BTDS20H SERIES (DIGITAL SWITCHES).pdf
BTDS20H SERIES (DIGITAL SWITCHES).pdf
BTDS20V SERIES (DIGITAL SWITCHES) BTDS20V SERIES (DIGITAL SWITCHES)
Rotary type digital code switch for vertical mount

- Clear detent operation perfect contact
- 8 to 40 detent codes are available
- Suitable design for guitar amp, and audio mixer
BTDS20V SERIES (DIGITAL SWITCHES).pdf
BTDS20V SERIES (DIGITAL SWITCHES).pdf
BTDS20HPT SERIES (DIGITAL SWITCHES) BTDS20HPT SERIES (DIGITAL SWITCHES)
Rotary digital code switch with push-on switch function

- Wonderful design for Digital code switch + Push-on switch
- Suitable for setting code with push-on switch
- Detent number 8 to 40 are available
BTDS20HPT SERIES (DIGITAL SERIES).pdf
BTDS20HPT SERIES (DIGITAL SERIES).pdf
